CAVSA series on site O2 generator, lower power consumption, lower operating and maintenance costs, smaller size of skid-mounted modular construction providing lower cost installation and saving floor space. CAVSA O2 generator with more adaptable to the environment, is a reliable and cost-effective solution for small to medium O2 requirements.
Key Features
● Lower power consumption, electricity consumption is only 0.7~0.9 kW per cubic meter of oxygen
● Skid-mounted and modular construction, smaller footprint and easy installation
● Maintenance is very simple, only need to change the inlet air filter element periodically, lower operating cost
● VSA technology, more adaptable to the environment and sea level of user jobsites, is more reliable
Models & Specifications
| Model | Capacity（Nm3/h） | Purity | Outlet Pressure | Dew Point | Power Consumption(kvh ) | Noise Level |
| CAVSA-10 | ≥10 | ≥90% | 0.1~0.3 Bar(g) | ≤-43℃ | 0.7kvh/Nm3@ 0.3bar， 0.86kvh/Nm3@ 4bar， 0.92kvh/Nm3@ 8bar | 80dB |
| CAVSA-15 | ≥15 | |||||
| CAVSA-20 | ≥20 | |||||
| CAVSA-25 | ≥25 | |||||
| CAVSA-30 | ≥30 | |||||
| CAVSA-40 | ≥40 | |||||
| CAVSA-50 | ≥50 |
Each Project is Custom-Built!
SPEAK WITH AN EXPERTAt CAN GAS, we listen to your demands and design the best possible solution for you. You can get the full line from air compressor to high quality cylinders – whatever your need may be.
We design your specific solution based on application, capacity, purity, pressure, classification requirements, ambient conditions, and height above sea level.
