SMART series PSA oxygen generators are developed for small health care institutions, especially for low flow, continuous medical oxygen demand. A stand alone system with highly compact , plug and run design and wide applicabilities. SMART series PSA oxygen generators are excellent in performance, reliability and convenience.
Key Features
● Oxygen purity≥93%.
● Complies with and exceeds the requirements of YY1468-2016 <Oxygen Concentrator Gas Supply System for Medical Gas Pipeline Systems>.
● Highly integrated: multiple devices are skillfully integrated into an industrial-grade silent chassis.
● Reliable and efficient: designed for 7x24 operation, with multiple operation monitoring and protection.
● Brand new design PI, one-button start, fully automatic operation.
● Economic and energy-saving: intelligent production management system, effectively reducing operating costs.
● Expansion and upgrade: flexible and convenient expansion and upgrade capabilities, enabling it to adapt to various application scenarios and more effectively meet oxygen demand.
● Quiet operation: professionally designed silent industrial chassis, sturdy and noise-reducing, greatly reducing noise interference.
● Freedom of movement: equipped with mobile casters, flexible placement in any desired location.
● Simplified Installation: One-step process, plug-and-play.
● CANBUS local multi-function monitoring system and Wi-Ctrl remote wireless monitoring system (optional) to realize remote monitoring of intelligent operation of equipment; keep track of system operation conditions at any time, and realize remote system upgrade.
Models & Specifications
Model | CAP-O-300/SMART 2C | CAP-O-300/SMART 3C | CAP-O-300/SMART 5C |
Oxygen Purity（%） | ≥93 | ≥93 | ≥93 |
Oxygen flow rate（Nm3/h） | 2-2.5 | 3-3.5 | 5 |
Oxygen Pressure（MPa） | ≥0.4 | ≥0.4 | ≥0.4 |
Dimension（mm） | 1600*900*1600 | 1600*900*1600 | 1600*900*1600 |
Weight（Kg） | 650 | 650 | 750 |
Each Project is Custom-Built!
SPEAK WITH AN EXPERTAt CAN GAS, we listen to your demands and design the best possible solution for you. You can get the full line from air compressor to high quality cylinders – whatever your need may be.
We design your specific solution based on application, capacity, purity, pressure, classification requirements, ambient conditions, and height above sea level.
